Durable and Energy-Saving LED Power Supply 12V 24V for Indoor Outdoor Led Light Module Point Source Light
| Lugar de origem | Cantão,China |
|---|---|
| Marca | Miracle Bean |
| Certificação | CE ROHS |
| Número do modelo | XH-400W |
| Quantidade de ordem mínima | 50 |
| Preço | negotiate |
| Detalhes da embalagem | 390*265*265 23kg |
| Tempo de entrega | Dentro de 3-5 dias úteis |
| Termos de pagamento | T/T adiantado, Western Union, Paypal, LC |
| Habilidade da fonte | 50000 unidades por mês |
Contacte-me para obter amostras grátis e cupões.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
Se tiver alguma preocupação, fornecemos ajuda online 24 horas por dia.
xDetalhes do produto
| Proteção | IP67 à prova d'água | Controle de escurecimento | Nenhum |
|---|---|---|---|
| Gabinete | Escudo de alumínio inoxidável de oxidação | Ampere de saída | 0 ~ 16,5A |
| Proteção contra sobretensão | Sim | Categoria | Fonte de alimentação LED à prova d'água IP67 DC 12V |
| Qualidade | excelente qualidade | Corrente da C.C. | 4.1A |
| Corrente de saída | 5a | Peso | 500g |
| Tipo de saída | AC-DC | Entrada do ventilador | 12V/24V |
| Material de caixa | Metal |
Descrição de produto
Durable and Energy-Saving LED Power Supply 12V 24V for Indoor Outdoor Led Light Module Point Source Light
Power Supply
LED power supply description
An LED driver is a specialized power supply that regulates the flow of electricity to power LED lights.
It converts the standard AC voltage from the electrical grid (Like 120V or 220V ) to the appropriate DC voltage (e.g., 12V or 24V) and current required by the LEDs.
This ensures the LEDs receive the correct amount of power to operate efficiently and safely, preventing damage from overvoltage or undervoltage.
Key Functions of an LED Driver:
1.Voltage Conversion:
LED drivers convert the input AC voltage to the specific DC voltage needed by the LEDs.
2.Current Regulation:
They regulate the current flow to the LEDs, ensuring they receive the correct amount for optimal performance and preventing damage.
3.Overvoltage/Undervoltage Protection:
LED drivers protect the LEDs from potentially damaging voltage fluctuations in the electrical grid.
4.Dimming and other features:
Many LED drivers also offer dimming capabilities and other features not found in standard power supplies.
LED power supply specificatoion
| Model | XH-100W-B | XH-24100-B |
| DC output voltage | 12V | 24V |
| Rated output current | 33.3A | 16.6A |
| Output current range | 0~33.3A | 0~16.6A |
| DC output power | 100W | 100W |
| Efficiency | 90% | 90% |
| Input voltage | AC 170-265V | |
| Waterproof level | IP67 | |
| Working temperature and humidity | -30~+50 centigrades 20-99% RH non-condensing(waterproof) | |
| Store temperature and humidity | -40~+80centigrades 10-99% RH | |
| Weight | 0.4kg | |
| Dimension | 225mm*53mm*19mm | |
LED power supply Protections:
1. Short Circuit: protection mode(revocers automatically after fault condition is removed.) So,if your power supply not work,please wait for 30 seconds,then start it again.Maybe its self-protection worked.
2. Overload Protection
3. Overtemperature:Protection model(shut down output votlage,work again after re-started.
Our Services
♦♦ Our led power supply Service
1. Replied in 24hrs
2. Answer all your enquires in fluent English
3. OEM & ODM are welcome
4. Distributoership are offered for your unique design and some our current models;
5. Protection of your sales area, ideas of design and all your private informaton
6. Provide lifelong warranty
7. After you buy this product, we will provide you with attentive after-sales service. Our engineers will carefully guide the installation and usage for you. That will includes connection of the controller and the light, and also the control software.
Applications
♦♦Led power supply Applications
1. Power For led strips,led modules,led pixel lights,
2. Power For outdoor lamps,led street lamps,led downlight,led flood light and so on
3. Power For CCTV,
4. Office lighting, Artwork lighting, Display case
5. Home lighting
6. Commercial lighting, such as Down light, Underground lamp, Panel light, Spotlight, Wall washer, etc.
7. Hotel, Restaurant lighting
8. Other public lighting
Company Information
♦♦ Shenzhen Xinhe Lighting Optoelectronics Co., Ltd.
- Specialized in semiconductor illumination and lighting products, and is an integral companyintegrating designing, developing, manufacturing, and sale.
- We focus on the appliance products in advertising and lighting area, and establish the long term business relationship with large advertisement material distributors.
- With topping technology talented persons, advanced management, efficient staff team, our company tries our best to create well-known brand in semiconductor illumination field.
- Our company bases on LED encapsulation, making the best lighting deploying projects in allusion to different LED appliance field.
- Our company captured the chance of revolution of world illumination industry, and formed application department.
- Our extended series products are as: the LED modules for advertising lighting, specialized LED switch power supply, LED RGB controllers, LED open signs, super LED straight lighting words and other related products.
LED power supply Show
